Three Phase Power Pole Mounted Oil Immersed Distribution Transformer 11kV
Key attributes
| Brand | Vziman |
| Model NO. | Three Phase Power Pole Mounted Oil Immersed Distribution Transformer 11kV |
| Rated frequency | 60Hz |
| Rated capacity | 45kVA |
| Series | S |
Product descriptions from the supplier
Description
Pole Mounted Distribution Transformer Product Description
45kVA Three Phase Power Pole Mounted Distribution Transformer Oil Immersed 12000V
Vzimas 45kVA Three Phase Pole Mounted Distribution Transformer—a high-efficiency variant of Power Distribution Transformer—boasts a round tank design, tailored for scenarios requiring three-phase power supply with limited installation space. As a specialized Pole Mounted Distribution Transformer, it delivers a neater power supply solution and lower installation costs compared to a bank of three single-phase units, outperforming conventional Power Distribution Transformer in space utilization and cost-effectiveness.
Equipped with a triplex core/coil structure, this Pole Mounted Distribution Transformer is optimized for powering electric motor loads, especially those with frequent motor start-up demands. Its oil-immersed insulation ensures stable operation in outdoor environments, making it a reliable Power Distribution Transformer choice for industrial workshops, commercial complexes, and small-scale manufacturing facilities that need compact, high-performance three-phase power supply equipment.
Pole Mounted Distribution Transformer Product Features
- Compact Pole-Mounted Design, Space-Saving：This Pole Mounted Distribution Transformer is a specialized three-phase variant of Power Distribution Transformer, engineered with a compact round tank structure that fits directly on utility poles. Unlike ground-installed Power Distribution Transformer, it requires no dedicated foundation, maximizing space utilization for scenarios with limited installation area.
- Oil-Immersed Insulation, Stable Outdoor Performance：The oil-immersed design of this Pole Mounted Distribution Transformer ensures superior insulation and heat dissipation, outperforming dry-type Power Distribution Transformer in harsh outdoor environments. It resists moisture, dust and temperature fluctuations, maintaining reliable operation for long periods without frequent maintenance.
- Triplex Core/Coil Structure, Motor Load Adaptability：Equipped with a triplex core/coil system, this Pole Mounted Distribution Transformer is optimized for electric motor loads with frequent start-ups. As a high-performance Power Distribution Transformer, it delivers balanced three-phase power, minimizing voltage fluctuations during motor operation and extending equipment service life.
- Cost-Effective, Low Installation & Operational Costs：Compared to a bank of single-phase units, this Pole Mounted Distribution Transformer cuts down installation time and labor costs significantly. As an integrated Power Distribution Transformer, it also reduces long-term operational expenses with its durable oil-immersed structure and low failure rate.
Power Distribution Transformer Main data
| Transformer Type | Overhead Distribution Transformer, Conventional Type |
| Transformer Polarity Type | Subtractive |
| Phase | Three Phase |
| Capacity | 45 KVA |
| Primary Voltage | 12000V |
| Secondary Voltage | 208Y/120 (L-N-L) |
| Frequency | 60 Hz |
| Temperature Rise | 65°C |
| Insulation Rating | Class E Insulation - 120°C, 248°F |
| Cooling Class | ONAN; Self-Cooled |
| Impedance | 3.75% |
| Efficiency Standard(s) | Meets DOE 2016 Standards, Meets ANSI/IEEE Standards |
| K-Factor Rating (Harmonic Mitigation) | K-1 (Standard) |
| Pulse Drive Rating | N/A |
| Winding Material | Copper |
| Ambient Temperature Rating | 40°C |
| Sound Level | 48 dBA |
| Dimensions* | 24''-W x 29''-D x 65''-H |
| Efficiency | 98.70% |
| Total Load Loss (in watts) | +/- 684W |
Power Distribution Transformer Standard Features
- Meets or exceeds current IEEE, NEMA standards.
- Triplex core/coil design.
- Wet process high voltage bushings.
- Molded polymer low voltage bushings.
- Tin plated bronze terminals suitable for copper or aluminum connection.
- Two tank grounding provisions.
- Lightning arrester mounting provisions.
- 1/2” drain plug.
- Automatic pressure relief device.
- Mineral oil.
- Mild steel tank and bolted cover.
- Laser engraved nameplate.
Power Distribution Transformer Application Scenarios
- Rural & Suburban Three-Phase Power Grids：Rural industrial parks and suburban commercial streets often need three-phase power but lack space for large substations. This Pole Mounted Distribution Transformer serves as a core Power Distribution Transformer here, supplying stable power to small factories, agricultural processing equipment and commercial complexes.
- Construction Sites & Temporary Power Projects：Construction sites require flexible, rapidly deployable three-phase power for cranes and concrete mixers. The Pole Mounted Distribution Transformer is a portable Power Distribution Transformer solution, easy to install and relocate, perfectly matching the temporary power demand of construction and emergency repair projects.
- Industrial Workshops & Small Manufacturing Facilities：Small-scale workshops with motor-driven equipment rely on balanced three-phase power supply. This Pole Mounted Distribution Transformer, as a dedicated Power Distribution Transformer, ensures stable voltage output, avoiding motor burnout caused by unbalanced currents and supporting continuous production operations.
Q: What advantages does the Three Phase Power Pole Mounted Oil Immersed Distribution Transformer have over single-phase models for industrial loads?
A:
This three-phase Pole Mounted Distribution Transformer delivers balanced voltage for motor-driven industrial equipment, outperforming single-phase Pole Mounted Distribution Transformer in load adaptability. As an oil-immersed Power Distribution Transformer, it boasts superior outdoor insulation and heat dissipation, ensuring stable long-term operation. It also saves more space than ground-installed Power Distribution Transformer, making it a cost-efficient choice for industrial and commercial scenarios with limited installation area.
Q: What advantages does the Three Phase Power Pole Mounted Oil Immersed Distribution Transformer have over single-phase models for industrial loads?
A:
This three-phase Pole Mounted Distribution Transformer delivers balanced voltage for motor-driven industrial equipment, outperforming single-phase Pole Mounted Distribution Transformer in load adaptability. As an oil-immersed Power Distribution Transformer, it boasts superior outdoor insulation and heat dissipation, ensuring stable long-term operation. It also saves more space than ground-installed Power Distribution Transformer, making it a cost-efficient choice for industrial and commercial scenarios with limited installation area.
