Solar Power Station 4300kVA/40.5kV Prefabricated Compact Transformer Substation

Solar Compact Prefabricated Substation Product Description

Solar Prefabricated Station Core Product Features

• High Integration Design, Adapted to Solar Power Station Layout:The Solar Compact Prefabricated Substation inherits the compact structural advantage of conventional compact substations, with all power conversion and distribution components integrated in a sealed box, featuring small footprint and light weight. This design is highly suitable for the decentralized layout characteristics of the Solar Prefabricated Station, which can be flexibly installed in photovoltaic panel clusters, avoiding occupying a large area of photovoltaic power generation land, and realizing integrated deployment with the power generation system.
• High Efficiency Power Conversion, Reducing Solar Power Station Loss:Optimized for the DC-AC conversion power characteristics of photovoltaic power generation, the Solar Compact Prefabricated Substation is equipped with a high-efficiency energy-saving transformer, with ultra-low no-load loss and load loss, which can maximize the conversion and utilization of electric energy generated by the Solar Prefabricated Station, effectively reducing the power loss in the step-up and distribution process, and improving the overall power generation efficiency of the photovoltaic project.
• Specialized Grid-Connection Design, Matching Solar Power Station Demand:The Solar Compact Prefabricated Substation has a customized grid-connection circuit design, which is perfectly compatible with the output parameters of solar photovoltaic inverters, and can realize smooth grid connection between the Solar Prefabricated Station and the municipal power grid/industrial power grid. It is equipped with a dedicated anti-islanding protection module, which meets the national new energy grid-connection standards and ensures the safety and stability of the photovoltaic power generation system and the public power grid during parallel operation.
• Sealed Protective Structure, Adapting to Solar Power Station Outdoor Environment:Adopting a fully sealed and weatherproof structural design, the Solar Compact Prefabricated Substation has excellent resistance to high temperature, ultraviolet radiation, dust and rain, which can adapt to the long-term outdoor operation environment of the Solar Prefabricated Station (mostly built in open areas such as roof, desert and plain). Its shell is treated with special anti-corrosion and anti-UV coating, effectively extending the service life of the equipment in harsh outdoor conditions.
• Intelligent Monitoring, Realizing Solar Power Station Unattended Operation:The Solar Compact Prefabricated Substation is equipped with an intelligent online monitoring system, which can real-time collect and transmit the equipment's operating parameters such as voltage, current, temperature and load. It supports remote data viewing and fault alarm, which is perfectly matched with the unattended operation mode of the large-scale Solar Prefabricated Station, reducing the on-site operation and maintenance workload and improving the management efficiency of the power generation project.

Solar Prefabricated Station product Parameters

Solar Prefabricated Station application

• Space-saving design fits roof installation conditions: The Solar Compact Prefabricated Substation has a compact structure and small footprint, which can be flexibly installed on the idle roof area of buildings without occupying the ground space of the enterprise or community, and perfectly adapts to the limited installation space of the roof distributed Solar Prefabricated Station.
• Lightweight structure adapts to roof load requirements: Optimized for roof bearing capacity, the Solar Compact Prefabricated Substation adopts a lightweight shell and integrated component layout, effectively reducing the overall weight of the equipment, avoiding exceeding the roof load limit of the building, and ensuring the structural safety of the building while realizing photovoltaic power generation.
• Sealed protection ensures safe roof operation: The fully sealed structural design of the Solar Compact Prefabricated Substation can effectively prevent rain, dust and bird damage, and the built-in comprehensive protection system (overvoltage, overcurrent, short circuit, lightning protection) eliminates electrical safety hazards, meeting the high safety operation requirements of the roof distributed Solar Prefabricated Station close to building crowds and flammable materials.
• High efficiency power conversion improves roof power generation benefits: Equipped with a high-efficiency energy-saving transformer, the Solar Compact Prefabricated Substation minimizes the power loss of the roof distributed Solar Prefabricated Station in the step-up process, maximizes the utilization of photovoltaic power generation, and directly improves the power generation income of enterprises and communities.
