Customizable 44kV 45kV 46kV Fully Integrated Skid Mounted Substation

Skid Mounted Substation Description

Engineered for global power distribution needs, our customizable 44kV/45kV/46kV Skid Mounted Substation is a fully integrated power solution, delivering seamless performance for industrial, utility, and remote infrastructure projects. This Skid Mounted Prefabricated Substation features a compact, all-in-one design that eliminates complex on-site assembly, enabling rapid deployment and easy relocation for diverse project scenarios. Fully compliant with IEC, IEEE, and CSA international standards, the Skid Mounted Substation supports full tailored configurations—including enclosure materials, transformer capacity, and intelligent monitoring systems—to match diverse regional grid requirements. Built for harsh outdoor environments, the Skid Mounted Prefabricated Substation offers unmatched reliability, energy efficiency, and cost-effectiveness, serving as a turnkey power distribution solution for global projects.

Skid Mounted Substation Feature

• Multi-Voltage Compatibility：The Skid Mounted Prefabricated Substation is customizable for 44kV/45kV/46kV systems, perfectly matching diverse regional grid specifications and adapting to the global power distribution needs of the Skid Mounted Substation.
• Fully Integrated Design：This Skid Mounted Substation adopts an all-in-one modular structure with pre-wired core components, minimizing on-site installation time by 60% and avoiding the construction delays of traditional substations for the Skid Mounted Prefabricated Substation.
• Flexible Customization：The Skid Mounted Prefabricated Substation provides diversified tailored options, including enclosure material (carbon steel/stainless steel), transformer capacity, and smart monitoring integration, fully meeting the personalized project requirements of the Skid Mounted Substation.
• Rapid Deployment & Relocation：Equipped with a dedicated skid-mounted base, the Skid Mounted Substation enables direct hoisting and on-site positioning, with flexible mobility that makes it ideal for temporary projects and remote area construction of the Skid Mounted Prefabricated Substation.
• Global Standards Compliance：The Skid Mounted Prefabricated Substation strictly meets IEC, IEEE, and CSA international standards, ensuring seamless compatibility with global power distribution projects and the universal application of the Skid Mounted Substation.
• Harsh Environment Resilience：The Skid Mounted Substation features a corrosion-resistant enclosure and sealed internal components, supporting stable operation under extreme temperatures, dust, and high humidity, and adapting to the harsh outdoor working conditions of the Skid Mounted Prefabricated Substation.

Skid Mounted Substation Component Structure

Project	Units	C Module	F Module	V Module		CB Module
		Load Switch	Combination Electric Appliance	Vacuum Switch	Isolation/Grounding Switch	Vacuum Circuit Breaker	Isolation/Grounding Switch
The Rated Voltage	KV	12	12	12	12	12	12
Rated Frequency	HZ	50	50	50	50	50	50
Power Frequency Withstand Voltage (Phase/Fracture)	KV	42/48	42/48	42/48	42/48	42/48	42/48a
Lightning Shock Withstand Voltage	KV	75/85	75/85	75/85	75/85	75/85	75/85
Rated Current	A	630	infuse1)	630		1250/630
Breaking Ability:
Rated Closed Loop Breaking Current	A	630
Rated Cable Charging Break Current	A	10
Rated Short Circuit Closing Current (Peak)	A	50	80
Rated Peak Tolerable Current	kA	50
Rated Short-Time Tolerable Current	kA/35	20
Rated Short Circuit Breaking Current	kA		31.5	20		25
Rated Transfer Current	A		1700
Use The Maximum Current Of The Fuse	A	-	125
Loop Resistance	-n	≤300	≤600
Mechanical Life	next	5000	3000	5000	2000	5000	2000
Note: Depends On Current Rating Of The Fuse
